Shanghai four macro mechanical and electrical line drive is a famous American AMETEK corp. , a subsidiary, the company recently launched a new BGS04 linear guide series, the product is a new open mold design products, especially suitable for applications where high bending load, a new structure design can make it in high lateral load and high cantilever load cases, still can ensure the position precision of the whole system and repeat positioning accuracy. BGS04 linear guide at the core of the driving part is composed of 303 stainless steel cork screw, screw with dry mix oil TFE coating, and the screw is to be used together with cork patent clearance nut, nut precision fixed inside the slide block, block made of aluminum alloy materials, durable, the power source of the whole system can choose four macros in Shanghai 28000 double fold thick motor or 43000 series. BGS04 linear guide is a new product that is designed to solve the problem of heavy load, which can withstand the maximum level, vertical and rotational direction of the shear stress of 6 respectively. 60NM,7. 70NM,7. 75 nm, the maximum horizontal load is 10 kg, the drive screw lead can choose according to customer's requirement, from 0. 635MM-25. Step 4 mm range of optional, cooperate from the Angle of 1. 8 degrees of stepper motor, the long step progress of linear guide to 0. 003MM-0. On a tour of length from 25 mm - 127 mm460 mm optional! If you choose 43000 series motor power supply, can also be equipped with Shanghai four macro IDEA of intelligent drive, the drive small size, powerful, integrated installation in the back of my machine, almost does not occupy a space, use very convenient! For more information please visit Shanghai four macros linear motor (Shenzhen)Co. , LTD. Web site, http://www. sihongmotor。 Cn the main products: stepper motor, brushless motor, servo motor, stepping motor drive, brake motor, linear motor and other kinds of models of the stepper motor, welcome to inquire. Telephone:
